Weight
Blue:
S: 11.5 kg
M: 11.6 kg
L: 11.7 kg
XL: 11.8 kg
Green
S: 11.3 kg
M: 11.4 kg
L: 11.5 kg
XL: 11.6 kg
Weight without pedals, with inner tubes
Frame
Full carbon
1150 g in size M (gross, without hardware)
31.6 mm seat post
Compatible with dropper posts (internal routing)
Thru axle
BOOST format
PressFit 92 bottom bracket
Compatible with 2 bottle cages
Sram UDH derailleur hanger
Drivetrain
Sram GX Eagle rear derailleur and shifter
Truvativ STYLO 6K crankset (170 mm in S and M, and 175 mm in L and XL)
32T chainring (compatible with 30, 32, 34 and 36T)
SRAM PG1230 11-50 cassette
Sram NX chain
Sram PF 92 bottom bracket
Suspension
GREEN MODEL (8731767)
RockShox REBA RL 100 mm fork
32 mm stanchions
Motion Control valve
Thru axle
BOOST format
Combolock II handlebar lockout (2 positions: open and closed)
Weight: 1633 g
BLUE MODEL (8615562)
RockShox Recon GOLD RL 100 mm fork
32 mm stanchions
Motion Control valve
Thru axle
BOOST format
Combolock II handlebar lockout (2 positions: open and closed)
Weight: 1850 g
Wheels
29" Sun Ringle Duroc 30 SRC Tubeless Ready wheels
Weight: 2070 g
HD freehub
Inner rim width: 30 mm
6-bolt rotors
32 round spokes
Sealed bearings
BOOST axles: 15 mm front and 12 mm rear
Fitted with rim tape: Tubeless Ready
Brakes
Sram Level T
Sram G2 180 mm front rotor and 160 mm rear
6-bolt rotors
Riding position
Rockrider aluminium stem
-7° angle
60 mm in size S
70 mm in size M
80 mm in size L
90 mm in size XL
Rockrider aluminium flat handlebar
720 mm wide
6.5° angle
256 g
Grips: Rockrider 900 Lock On
Saddle and seat post
Saddle Rockrider XC Ergofit
265 g
31.6 mm aluminium
Length: 350 mm (size M) and 400 mm (size L and XL)
285 g
Tyre
Front: Vittoria Barzo 29 x 2.25 Graphene
120 TPI carcass
Weight: 720 g
Rear
Vittoria Mezcal 29 x 2.25 Graphene
120 TPI carcass
Reinforced sidewalls
Weight: 760 g
Pedals
Rockrider 520 Grip resin flat pedals
Accessories
Your mountain bike comes with a bell, lighting, wheel reflectors, and pedals
